Pro-Tech BE-0986 - BE-0986 Specifications

Chapter 2 Getting Started
BE-0986 SERIES USER MANUAL
Page: 2-3
2.2 BE-0986 Specifications
System
CPU
 BE-0986RA-D0N & BE-0986RA-N0N: Intel
®
Celeron
N3350 (apollolake)
 BE-0986RA-D1N & BE-0986RA-N1N: Intel
®
Pentium
N4200 (apollolake)
Memory Support
 1x SO-DIMM socket supporting 1600/1867 DDR3L
memory up to 8G (non-ECC)
Power Supply
 Supports 12~24V DC power input
Dimension
 3.5” SBC Platform, 102mm x 145mm, 1.6mm PCB
thickness
O.S. Support
 Windows
®
10 64bit
 Ubontu17.04 64bit
BIOS
 AMI UEFI BIOS
I/O Ports
USB
 2 x USB 2.0 (internal wafer)
 4 x USB 3.0(Rear I/O)
Serial Ports
 4 serial ports (internal pin header)
 COM1: RS232
 COM2: RS232/422/485, selected by BIOS, default:
RS232
 COM3: RS232 with 5V/12V/RI selectable by jumper
 COM4: RS232 with 5V/12V/RI selectable by jumper
 COM3/4 port pin9 power limit: 0.5A
LAN
 Dual LAN (2xRJ45 on rear I/O)
 Supports Wake-On-LAN
 Controller: 2 x Intel I210-IT (MAC+PHY, PCIe interface)
GPIO
 Programmable 8 bit GPIO (Default setting is 8GPI
every time when system AC power is re-applied from
power failure state.
 GPI/GPO configuration can be set by Protech’s API.
 Configuration can still be kept even in S5 state unless
system AC power is lost.
 GPIO pin header provides 5V power Pin / GND pin.
SATA Interface
 1 x SATA III port (6.0Gb/sec)
Expansion Slot/mSATA
 1 x full-sized mSATA slot (with SATA and USB signals)
