Chapter 2 Getting Started
BE-0986 SERIES USER MANUAL
Page: 2-4
1 x full-sized mPCIe slot (with PCIe and USB signals)
Display
Display
1 x HDMI1.4a (Rear IO), resolution: up to 4096x2160
@24Hz
1 x VGA(Rear IO), resolution: up to 1920x1200@60Hz
1 x LVDS (internal connector), Dual Channel, 24-bit.
Resolutions are set by Slide Switch
LVDS connector supports LVDS_VCC 3.3V/5V
(selected by jumper, default: 3.3V)
LVDS Backlight
JINV 5-pin connector supports 12V, PWM for panel
backlight power/dimming:
- PWM’s voltage level is 3.3V/5V (selected by jumper,
default: 3.3V)
- PWM’s duty cycle can be controlled by Windows and
Protech’s utility (from API)
- BLEN pin voltage is 3.3V only
Front Panel
2 x 5 pin header: HDD LED/ PWR LED / RST BTN /
PWR BTN
Power Mode
Power Mode
Power on mode:
- BIOS Power fail on: boot-up when AC power returns
from Off to On (default)
- BIOS Power fail off: non-boot-up when AC power
returns from Off to On
Way to Boot-Up from S5:
(1) Power Button
(2) Wake-On-LAN (3) RTC-wake (set by BIOS)
Way to Shutdown to S5/S4/S3:
(1) Power Button
(2) OS command
Supports S0/S3/S4/S5
Note: BIOS default setting: BIOS Power fail On.
Others
Sound
Line-in / Line-out / MIC-in (onboard pin header)
Codec IC: Realtek ALC888 (High Definition Codec)
Other I/O, Bus Function
1 x I2C 4-pin wafer
I2C (read/write function) is supported by Protech’s
Utility & API
1 x 4-pin FAN connector (with speed control/monitoring
by API / BIOS)
