Chapter 5 BIOS Setup
BE-0986 SERIES USER MANUAL
Page: 5-34
South Bridge - PCI Express Configuration
Menu Path Chipset > South Bridge > PCI Express Configuration
PCI Express Configuration Screen
BIOS Setting
Options
Description/Purpose
PCI E Express Root Port 1
(I210 LAN)
Sub-menu
PCIE RP1 parameters (I210 LAN).
PCI E Express Root Port 2
(I210 LAN)
Sub-menu
PCIE RP2 parameters (I210 LAN).
PCI E Express Root Port 3
(Mini-PCIe)
Sub-menu
PCIE RP3 parameters (Mini-PCIe).
