Procon V3D - Virtual Input Configuration

H - I - J PROGRAMMER’S MANUAL V8.94.11-
- 35 -
Submenu
Explanation, further submenus
Values
Default setting
Unit
4-11
digital input 1.
Selecting logical function commands and activation of program or counter function can be made
here!
4-11-1 type selection
N: It means inactive input, except for IRE input.
(see: page 41)
N
logical functions
program func.
other functions
logical functions
4-11-2 logical functions
logical functions
(see: page 36)
4-11-3 program functions
program funct.
(see: page 38)
4-11-4 other functions
other functions
(see: page 38)
4-11-5 active state
With closing or opening contact
closing
opening
closing
4-11-6 name
xxxxxxxx
dig.in 1
4-12
digital input 2.
The setting is the same as that of item 4-11 digital input 1.
* digital input 7-8 at VLD and VHD types only
●
●
●
4-18
digital input 8. *
4-21
virtual input 1.
Similarly to the built up digital inputs, with the use of the internal signal selected in the “Source”
menu item selection of logical function commands, activation of programs or counter function can
be done.
4-21-1 type selection
N: means inactive input
N
logical functions
program func.
other functions
logical functions
4-21-2 logical functions
logical functions
(see page 36)
4-21-3 program functions
program funct.
(see page 38)
4-21-4 other functions
other functions
(see page 38)
4-21-5 signal source
The input should comply with the state of what.
compare 1
compare 2
compare 3
period 1,2,3
period 1
period 2
period 3
MOD bus
compare 1
4-21-6 name
xxxxxxxx
vir.in 1
4-22
virtual input 2.
The setting is the same as that of item 4-21 virtual input 1.
●
●
●
4-26
virtual input 6.
