10 Operational Specifications
10.1 Absolute Maximum Ratings
Parameter
Symbol
Limits
Unit
DC supply voltage
VCC
-0.3 to 3.9
V
Input voltage
V
I
-0.3 to 5.5
V
Output voltage
V
O
-0.3 to VCC +0.3
V
DC output current
I
O
See Figure 10-4
mA
Storage temperature
T
store
-40 to +150
°C
Figure 10-1: Absolute Maximum Ratings
10.2 Recommended Operating Conditions
Parameter
Symbol
MIN
MAX
Unit
DC supply voltage
VCC
3.00
3.6
V
Static supply current
I
cc
100
1)
µA
Circuit ground
GND
0
0
V
Input voltage
V
I
0
5.50
V
Input voltage (HIGH level)
V
IH
2.00
5.50
V
Input voltage (LOW level)
V
IL
0
0.8
V
Output voltage
V
O
0
VCC
V
Ambient temperature
T
A
-40
+85
°C
1)
:
Static I
DD
current is exclusively of input/output drive requirements and is
measured with the clock stopped and all inputs tied to VCC or GND.
Figure 10-2: Recommended Operating Conditions
10.3 General DC Characteristics
Parameter
Symbol
MIN
TYP
MAX
Unit
Input LOW current
I
IL
-1
+1
µA
Input HIGH current
I
IH
-1
+1
µA
Tri-state leakage current
I
OZ
-10
+10
µA
Current consumption (3.3V)
I
A
30
mA
Input capacitance
C
IN
5
pF
Output capacitance
C
OUT
5
pF
Bi-directional buffer
capacitance
C
BID
5
pF
Thermal Resist. (BGA48)
Θ
JA
43.6
K/W
Thermal Resist. (QFP48)
Θ
JA
72.2
K/W
Figure 10-3: General DC Characteristics
