3.2.4 Synchronous Motorola Mode
In Synchronous Motorola Mode the data and address busses are separate
(non-multiplexed). When using HC11 types with a multiplexed bus the
address signals AB[7:0] must be generated from the DB[7:0] signals
externally. Address line 11 is to be connected to pin C5 of the VPC3+S.
XDTACK mechanism is not supported.
Ball
BGA
Pin
QFP
Signal Name
In/Out
Description
Connect to
E3
9
SERMODE
I
‘0’: Parallel Interface
GND
E4
28
MOT/XINT
I
‘1’: Motorola Format
VCC
D4
33
MODE
I
‘1’: Synchronous Interface Mode
VCC
C5
35
AB11
I
Address Lines Bit 11
CPU Address Bus 11
C2
2
AB10
I
Address Lines Bits [10:0]
CPU
Address Bus [10:0]
B3
44
AB9
I
A1
48
AB8
I(S)
B1
1
AB7
I(S)
C3
45
AB6
I
B2
46
AB5
I
B4
41
AB4
I
A5
38
AB3
I
A6
37
AB2
I
B5
39
AB1
I
B6
36
AB0
I
G4
20
DB7
IO
Data Bus [7:0]
CPU Data Bus [7:0]
H5
23
DB6
IO
H6
24
DB5
IO
G5
22
DB4
IO
G6
25
DB3
IO
F4
21
DB2
IO
F6
27
DB1
IO
F5
26
DB0
IO
C1
3
XCS
I
Chip-Select Signal (active low)
CPU Chip-Select
D5
32
E_CLOCK
I
E-Clock
CPU E-Clock
C6
34
R_W
I
Read-Write Signal (‘1’ = Read)
CPU Read-Write
Figure 3-7: Interface Configuration: Synchronous Motorola Mode
