5.1.3 Mode Register 2
Setting parameters for Mode Register 2 may take place in the Offline
State only (like Mode Register 0).
Address
Bit Position
Designation
7
6
5
4
3
2
1
0
0
0
0
0
0
0
0
1
Reset Value
0CH
4kB_Mode
No_Check_ Prm_Reserved
SYNC_Pol
SYNC_Ena
DX_Int_Port
DX_Int_Mode
No_Check_ GC_Reserved
GC_Int_Mode
Mode Reg 2
7 .. 0
