Operational Specifications 10
VPC3+S User Manual
Revision 1.04
115
Copyright © profichip GmbH, 2012
No.
Parameter
MIN
MAX
Unit
1
ALE pulsewidth
10
ns
2
ALE to XRD
20
ns
3
Address to ALE setuptime
10
ns
4
Address holdtime after ALE
0
ns
5
XRD to data valid
83
ns
6
XRD pulsewidth
105
ns
7
XRD to ALE
10
ns
8
address (AB7..0) holdtime after XRD/XWR
0
ns
9
data holdtime after XRD
3
12
ns
10
XRD / XWR cycletime
155
ns
11
ALE to XWR
20
ns
12
XWR pulsewidth
83
ns
13
data setuptime to XWR
10
ns
14
XWR to ALE
10
ns
15
data holdtime after XWR
0
ns
Figure 10-10: Timing, Synchronous Intel Mode
