Profichip VPC3+S - Page 122

10 Operational Specifications
122
Revision 1.04
VPC3+S User Manual
Copyright © profichip GmbH, 2012
No.
Parameter
MIN
MAX
Unit
43
address setuptime to AS
0
ns
44
AS to data valid
83
ns
45
AS pulsewidth (read access)
115
ns
46
R_W setuptime to AS
10
ns
47
XCS setuptime to AS
5
ns
48
AS to XDTACK (Normal-Ready)
125
ns
49
AS to XDTACK (Early-Ready)
104
ns
50
last AS to XCS
93
ns
51
AS cycletime
125
ns
52
address holdtime after AS
0
ns
53
Data holdtime after AS
3
12
ns
54
AS inactive time
10
ns
55
R_W holdtime after AS
10
ns
56
XCS holdtime after AS
0
ns
57
XDTACK holdtime after AS
3
15
ns
58
Data setuptime to AS
10
ns
59
AS pulsewidth (write access)
83
ns
60
Data holdtime after AS
0
ns
Figure 10-19: Timing, Asynchronous Motorola Mode
