4 Memory Organization
24
Revision 1.04
VPC3+S User Manual
Copyright © profichip GmbH, 2012
Address
Intel Mot.
Name Bit No.
Significance
30H
R_Prm_Buf_Ptr
Segment base address of the Prm_Buf
31H
R_Len_Cfg_Data
Length of the input data in the Cfg_Buf
32H
R_Cfg_Buf_Ptr
Segment base address of the Cfg_Buf
33H
R_Len_Read_Cfg_Data
Length of the input data in the
Read_Cfg_Buf
34H
R_Read_Cfg_Buf_Ptr
Segment base address of the
Read_Cfg_Buf
35H
R_Len_DXB_Link_Buf
Length of the DXB_Linktable
36H
R_DXB_Link_Buf_Ptr
Segment base address of the
DXB_Link_Buf
37H
R_Len_DXB_Status_Buf
Length of the DXB_Status
38H
R_DXB_Status_Buf_Ptr
Segment base address of the
DXB_Status_Buf
39H
R_Real_No_Add_Change
This parameter specifies whether the
Station_Address may be changed again
later.
3AH
R_Ident_Low
The user sets the parameters for the
Ident_Number_Low value.
3BH
R_Ident_High
The user sets the parameters for the
Ident_Number_High value.
3CH
R_GC_Command
The Control_Command of Global_Control
last received
3DH
R_Len_Spec_Prm_Buf
If parameters are set for the
Spec_Prm_Buffer_Mode (see Mode
Register 0), this cell defines the length of
the Prm_Buf.
3EH
R_DXBout_Buf_Ptr2
Segment base address of DXBout_Buf 2
3FH
R_DXBout_Buf_Ptr3
Segment base address of DXBout_Buf 3
Figure 4-4: Assignment of the Organizational Parameters
