5 Overview of equipment and control elements
5.1
Overview of equipment
1
P_G_0103_SW
2 3
Fig. 2: Overview of equipment DFXa, complete
1 Control unit
2 Drive unit
3 Liquid end
P DX 0177 SW
1
2
3
4
5
Fig. 3: Liquid end DFXa
1 Dosing head
2 Pressure connector (delivery status)
3 Suction connector (delivery status)
4 Star screws
5 Bearing cover
Overview of equipment and control elements
15
