7 Assembly
User qualification: Technical personnel and service - see
Ä ‘Qualification
of personnel’ on page 12
Refer to the correct dimensional drawings for the pump
from the online version of the operating instructions on
our website. www.prominent.com
Compare the dimensions on the dimensional drawing
with those of the pump.
CAUTION!
Danger from incorrectly operated or inadequately main‐
tained pumps
Danger can arise from a poorly accessible pump due to
incorrect operation and poor maintenance.
– Ensure that the pump is accessible at all times.
–
Adhere to the maintenance intervals.
7.1 Changing dosing head alignment
The dosing head can be aligned in 4 directions:
Fig. 7: Alignment of dosing head: to the right, to the left, up, down
To change the dosing head alignment, proceed as follows:
