Identifier Meaning
Only with
‘Access protection’
: the pump software is locked.
‘AUX’
The pump is currently pumping at auxiliary capacity.
‘memory’
Only in
‘CONTACT’
and
‘BATCH’
operating modes:
the auxiliary function "Memory" has been set.
The pump is in
‘ANALOG’
operating mode.
The
‘Curve
è
linear’
type of processing is set.
The pump is in
‘ANALOG’
operating mode.
The
‘Curve
è
Upper side band’
type of processing is set.
A hose rupture indicator is connected.
The pump is in the
‘Menu’
(Set up).
Further explanations can be found in the "Trouble‐
shooting" chapter.
The pump only shows the metering volume and the
capacity in the calibrated state in l or l/h or in gal or gal/h
(US gallons).
5.2.2 Key functions
Key Application In the continuous displays In the menu
[Back]
press - Go back to the previous menu
item (or a continuous display) -
without saving
[STOP/
START]
press Stop pump, Stop pump,
Start pump Start pump
[Menu]
press Go to the menu Go back to a continuous display
[Priming]
press Priming * Priming *
[Clickwheel]
press Start batch (only in
‘Batch’
operating
mode),
Acknowledge errors
Go to next menu item (or a contin‐
uous display)
Confirm entry and save
[Clickwheel]
turn Switch between the continuous dis‐
plays
Change figure or change selection
Overview of equipment and control elements
18
