LED display Colour lit lights up flashes
Operating display green The pump is ready for
operation
- -
During every revolution:
Capacity greater than 10
l / h
-
During every 1/2 revolu‐
tion:
Capacity less than 10 l /
h
-
During every 1/8 revolu‐
tion:
Capacity less than 1 l / h
-
every 4 s:
Capacity less than 500
ml / h
-
6.7 Hierarchy of operating modes, functions and fault statuses
The different operating modes, functions and fault statuses have a dif‐
ferent impact on whether and how the pump reacts.
The following list shows the order:
1. - Priming
2. - Stop
3. - Error, Pause
4. - Auxiliary capacity
5. - Manual, Analog, Contact, Batch, Fieldbus
Comments:
re 1. - “Priming" can take place in any pump mode (providing it is
working).
re 2. - "Stop" stops everything.
re 3. - "Error", and "Pause" stop everything apart from "Priming".
re 4. - "Auxiliary capacity" always has priority over the capacity specified
by an operating mode listed under 5 or the fieldbus.
