18.4 Material specifications
Part Material
Pump hose * TPV or PUR
Hose connection * PVDF
O-rings * PTFE
Dosing head PA6 50 % GB
Rotor PPS 40 % GF
Rollers on the rotor PA66
Bearing cover PC
Housing upper part PPE + 20 % GF
Housing lower part PPE + 20 % GF
Cable threaded connectors PA6
Metal parts (screws, etc.) A2
* wetted
18.5
Electrical data
Data Value Unit
Nominal power, approx. 45 W
Current I
eff
0.45 ... 0.20 A
Fuse 1.6 AT
Fuses must have VDE, UL and CSA certification. E.g. series SPT, 1.6 A
supplied by Schurter Order. No. 0001.2506 according to IEC Publ. 127 -
2/3.
18.6
Temperatures
Data Value Unit
Storage and transport temperature: - 10 ... +50 °C
Ambient temperature in operation (power
end/drive and control):
-10 ... +45 °C
Feed chemical temperature -10 ... +45 °C
Feed chemical temperature, briefly (5 min) +80 °C
Design: 100 - 230 V ±10%, 50/60 Hz
Pump, fully assembled
Technical data
99
