2.
Core hole
Adhere to the 3.5 mm Ø as the core hole diameter for screwing in the fixing
bolts.
Drill four holes for the bolts for the top section of the controller housing using a 3.5
mm Ø drill bit
3. Drill three holes for the bolts for the bottom section of the controller housing using
a 4.5 mm Ø drill bit
4. Drill four holes using an 8 mm Ø drill bit and use a jigsaw to cut the cut-out
ð
Deburr all the edges.
Assembly and installation
