ProMinent gamma/ X Supplementary Operating Instructions

Modul
e/slot
Index Name Modul
e
name
Diag.
numbe
r
Identi‐
fication
(hex)
Type Data‐
flow *
Description
4 Batch
memor
y
12 u8 If "Batch Memory" is activated
and a new batch is activated
during a batch metering already in
progress, the remaining metering
volumes are increased by that of
the new batch. If the "Batch
Memory" is not activated, the
remaining volume is deleted and
the new batch started.
5 Remai
ning
volume
13 f32 R The remaining volumes to be
metered in batch mode
7 1 Con‐
tact
volume
Con‐
tact
14 80.84 f32 S Volumes that are metered per
contact
2 Con‐
tact
memor
y
14 u8 - see "Batch Memory"
8 1 Con‐
centra‐
tion
rate
Con‐
cen‐
tration
15 C0,83,
83
f32 S Concentration setting setpoint
(only in
‘Concentration’ operating
mode)
2 Actual
con‐
centra‐
tion
16 f32 R Concentration setting actual value
(only in
‘Concentration’ operating
mode)
9 1 Meterin
g mon‐
itor
Meteri
ng
Mon‐
itor
17 80.80 u8 S If metering monitoring is installed,
it can be activated by yourself (1).
Deactivate is 0.
* R = read, W = write
Tab. 36: Error / Warning
Modul
e/slot
Index Name Module
name
Diag.
numb
er
Identi‐
fication
(hex)
Type Data‐
flow *
Description
10 1 Error Error /
Warnin
g
18 40.85 u32 R Bit Name Function
0 Min‐
imum
Metering
medium level
is too low
1 Batch Too many
metering
strokes: > 100
000
2 Analog
< 4mA
Analogue cur‐
rent is less
than 4 mA
3 Analog
> 23mA
Analogue cur‐
rent is greater
than 23 mA
Supplementary Operating Instructions PROFIBUS
®
74

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
