6
Assembly
CAUTION!
Danger of material damage
The device can be damaged by incorrect or improper storage
or transportation!
– The unit should only be stored or transported in a well
packaged state - preferably in its original packaging.
– The packaged unit should also only be stored or trans‐
ported in accordance with the stipulated storage condi‐
tions.
– The packaged unit should be protected from moisture
and the ingress of chemicals.
CAUTION!
Warning about personal and material damage
Personal and material damage may be caused if the unit is
operated outside of the permissible ambient conditions.
– Please observe the permissible ambient conditions -
refer to the chapter entitled "Technical Data".
WARNING!
Danger of electric shock
If water or other electrically conducting liquids penetrate into
the drive housing, in any other manner than via the pump's
suction connection, an electric shock may occur.
– Position the pump so that it cannot be flooded.
WARNING!
The pump can break through the supporting floor or slide off
it
– The supporting floor must be horizontal, smooth and per‐
manently load-bearing.
Capacity too low
Vibrations can disturb the valves of the liquid end.
–
The supporting floor must not vibrate.
Supporting floor
Fig. 12
Assembly
