Fig. 43: Sigma/ 1 SST bleed valve
Item Description Part no.
10 Integrated bleed valve, complete, DN10 SSA 1041071
10 Integrated bleed valve, complete, DN10 SSE 1041072
* The items listed are included in the spare parts kit. Springs made from Hastelloy C, O-rings from FPM-A and EPDM.
Technical changes reserved.
Sigma/ 1 SST bleed valve
Exploded view drawings
92
