Step 2: Connect the Pegasus32 to your Windows computer
InsertoneendofaThunderbolt™3/USBcableintotheThunderbolt™3/USBPort A on the
Pegasus32andconnecttheotherendofthecabletoaThunderbolt™3/USBportonyourcomputer.
MakesurethecableconnectorisorientedcorrectlytotheportonboththePegasus32andthe
computer.Itshouldteasilyinplacewhencorrectlypositioned.
Thunderbolt™ 3 / USB 3.2 Gen 2 data connecon and power connecon
To power source
Powercable
Thunderbolt™3/USBcable
Thunderbolt™3USB3.2Gen2(Type-C)ports
Windows computer
Thunderbolt™3
orUSBType-C
port on computer
Type-CMaleconnector Type-CFemaleport USB3.2Gen2icon Thunderbolt™icon
MakesurethecomputerportisaType-Cfemaleconnection.IftheportisaThunderbolt™3port,youwillseea
Thunderbolt™iconnexttotheport.IftheportisaUSB3.2Gen2port,youwillseetheUSB3.2Gen2iconnextto
the port.
