Empty drive carrier side view

Front

Empty drive carrier top view

Front

driVe CArrier hArdwAre

InStallIng dISk drIVeS

The Vess A6120 system supports:

• SATAharddisks

• 3.5-inchharddiskdrives

For a list of supported physical drives, download the latest compatibility list from the PROMISE support website.
