mAnAgement PAth - network ConneCtion
The Gigabit Ethernet RJ-45 ports on the rear panel for the network connection used for device administrator.
These ports must be physically and logically located in the IP subnet used by the system administrator.
Toestablishthemanagementpath:
1. Attach one end of an Ethernet cable to the network connector or standard NIC in the Host PC.
AttachtheotherendoftheEthernetcabletooneoftheportsonthestandardnetworkswitchonthe
subnetusedforsystemadministration.
2. Attach one end of an Ethernet cable to one of the ports on the same network switch or subnet used for
system administration.
AttachtheotherendoftheEthernetcabletooneofthe1000BASE-TportsonthebackoftheVess
A6120.
IfyouhavemultipleVessA6120systems,HostPCsorServers,repeatsteps1and2asrequired.
3. Follow the instructions for connecting to, and conguring the basic settings of the Vess A6120.
Please note that you do not need to establish a network connection for the initial setup. The web-based
management interface is accessible using a keyboard and monitor directly attached to the device. See the
next section for instructions.
20
Vess A6000 Series NVR Server Promise Technology
