Promise Technology Vess A Series User Manual

Bottom of 3.5” HDD
Screw holes for
mounting 2.5” SSD
or HDD
Mounting screws
Mounting screws (3.5” HDD)
Drive carrier handle (front)
1. Place the physical drive on a table with the bottom side facing up.
2. Position the drive in the carrier over the physical drive so the mounting holes line up (see below)
Notetherearedifferentmountingscrewholesfor2.5”drives.
3. Insert the screws through the proper holes in the carrier and into the drive or adapter.
• Installfourscrewsperdrive.
• Snugeachscrew.Becarefulnottoovertighten.
4. With the drive carrier handle in open position, gently slide the drive carrier into the enclosure.
Important
Press the release button to push the drive carrier into position.
Proper drive installation ensures adequate grounding and minimizes
vibration. Always attach the drive to the carrier with four screws.
18
Vess A6000 Series NVR Server Promise Technology
