Installation and Initialization MP.11-R Installation and Management
Product Package
19
Mounting Kit Kit includes the following:
A. Mounting clamp for wall/pole
B. Extension arm
C. Mounting plate to enclosure
D. Mounting clamp for pole mounting
Mounting Hardware The following mounting hardware, included with the mounting kit:
Quantity Description
6 ea. Plain washer #5/16
2 ea. Hex Cap Screw NC 5/16-18 x 35
2 ea. Nut NC 5/16-18
4 ea. Helical Spring Lock Washer #1/4
4 ea. Helical Spring Lock Washer #1/16
2 ea. Hex Cap Screw NC 5/16-18 x 80
4 ea. 68764,
Screw, Machine, Pan,
Philips, 1/4"-20, 5/8"L
