Technical Specifications MP.11-R Installation and Management
Management
226
Management
LEDs
Power Requirements
Physical and Environmental Specifications
Category Specification
Local RS-232 Serial port (RJ11 port built-into the unit; DB9 female via a converter, included)
Remote HTTP Server (RFC 2616); Telnet (RFC 855), TFTP Client (RFC 783), Link Test, SU/BSU
Statistics, temperature logging, remote reboot/reset
SNMP SNMPv1/v2 (RFC 1157); SNMPv2c (RFC 1907); MIB-II (RFC 1213); Ethernet-like MIB
(RFC 1643); BridgeMIB (RFC 1483); 802.3MAU (RFC 2668); 802.11 MIB; Private MIB;
ORiNOCO MIB
Category Specification
Types Two indicators on RJ45 connector to indicate:
• Power
• Wireless Activity
• Ethernet Activity
Category Specification
Power-over-Ethernet • Custom Power over Ethernet (802.3af compatible)
• Input: Voltage 110 to 250 VAC (47-63Hz)
• Output: 48V @ 420mA MAX (injected into the CAT-5 Cable)
Outdoor Radio Unit • Power Consumption: 7.5W typical. Up to 20 Watts across full
operating temperature range.
• Input: Voltage 42 to 60 VDC
Category Specification
Physical
Dimensions (unpackaged) • All Base Station and Subscriber Units with Type-N Connector:
10.79 in x 11.14 in x 3.38 in (274 mm x 283 mm x 86 mm)
• Subscriber Units with Integrated 23 dBi or 21 dBi Antenna:
12.60 in x 12.60 in x 3.72 in (320 mm x 320 mm x 94.5 mm)
Weight (unpackaged) • Model 2454-R, 5054-R, and 5054-R-LR Base Station and Subscriber Units with
Type-N Connector:
5.95 lbs (2.7 kg) Unit-only; .45 lbs (.20 kg) for power supply
• Model 2454-R, 5054-R, and 5054-R-LR Subscriber Units with Integrated 23 dBi
Antenna:
6.5 lbs (2.92 kg) Unit-only,.45 lbs (.20 kg) for power supply
• Model 4954-R Base Station and Subscriber Unit with Type-N Connector:
6.9 lbs (3.1 kg) Unit-only; .45 lbs (.20 kg) for power supply
• Model 4954-R Subscriber Unit with Integrated 21 dBi Antenna:
7.5 lbs (3.4 kg) Unit-only,.45 lbs (.20 kg) for power supply
