Technical Specifications MP.11-R Installation and Management
OFDM Modulation Rates
219
OFDM Modulation Rates
NOTE: Maximum packet size: 1526 Bytes
Wireless Protocol
Interfaces
Receive Sensitivity
NOTE: BER=10-6
NOTE: Rx Sensitivity values will have a tolerance of +/- 2 dB.
Model 2454-R
Model 4954-R
Modulation Rate
20 MHz Channels 10 MHz Channels 5 MHz Channels
BPSK 6 and 9 Mbps 3 and 4.5 Mbps 2.25 and 1.5 Mbps
QPSK 12 and 18 Mbps 6 and 9 Mbps 3 and 4.5 Mbps
16-QAM 24 and 36 Mbps 12 and 18 Mbps 6 and 9 Mbps
64-QAM 48 and 54 Mbps 24 and 36 Mbps 12 and 18 Mbps
Category Specification
Wireless Protocol Worp (Wireless Outdoor Router Protocol
Category Specification
Wired Ethernet Auto-sensing 10/100BASE-TX Ethernet
Serial Connector RJ11 port built-into the unit, DB9 Female via a converter
included
Antenna Connector for BSU and
SU with Type-N Connector
Standard Type-N Female
Modulation 20 MHz Channels 10 MHz Channels 5 MHz Channels
64QAM ¾ -71 dBm @ 54 Mbps -74 dBm @ 27 Mbps -77 dBm @ 18 Mbps
64QAM ½ -74 dBm @ 48 Mbps -77 dBm @ 24 Mbps -80 dBm @ 12 Mbps
16QAM ¾ -79 dBm @ 36 Mbps -82 dBm @18 Mbps -85 dBm @ 9 Mbps
16QAM ½ -84 dBm @ 24 Mbps -87 dBm @12 Mbps -90 dBm @ 6 Mbps
QPSK ¾ -87 dBm @ 18 Mbps -90 dBm @ 9 Mbps -93 dBm @ 4.5 Mbps
QPSK ½ -89 dBm @ 12 Mbps -92 dBm @ 6 Mbps -95 dBm @ 3 Mbps
BPSK ¾ -91 dBm @ 9 Mbps -94 dBm @ 4.5 Mbps -97 dBm @ 2.25 Mbps
BPSK ½ -91 dBm @ 6 Mbps -94 dBm @ 3 Mbps -97 dBm @ 1.5 Mbps
Modulation
20 MHz Channels 10 MHz Channels 5 MHz Channels
64QAM ¾ -71.4 dBm @ 54 Mbps -76.2 dBm @ 27 Mbps -78.4 dBm @ 13.5 Mbps
64QAM ½ -72.9 dBm @ 48 Mbps -82.2 dBm @ 24 Mbps -79.9 dBm @ 12 Mbps
