Configuration MP.11-R Installation and Management

Network Parameters

The Network tab contains the following sub-tabs. Note that the availability of some sub-tabs depends on whether the unit

is in Bridge or Routing Mode.

• IP Configuration

• Roaming

• DHCP Server

• Spanning Tree (Bridge Mode Only)

• IP Routes (Routing Mode only)

• DHCP Relay Agent (Routing Mode Only)

• SNTP-DNS

IP Configuration

Click Configure > Network > IP Configuration to view and configure local IP address information. Configurable settings

differ between Bridge mode and Routing mode.

Bridge Mode

If the device is configured in Bridge mode, the following screen is displayed:

Configure or view the following parameters:

• IP Address Assignment Type:

–Select Static if you want to assign a static IP address to the unit. Use this setting if you do not have a DHCP

server or if you want to manually configure the IP settings

–Select Dynamic to have the device run in DHCP client mode, which gets an IP address automatically from a

DHCP server over the network.

When the unit is in Bridge mode, only one IP address is required. This IP address also can be changed with ScanTool

(see Setting the IP Address with ScanTool).

• IP Address: The unit’s static IP address (default IP address is 10.0.0.1). This parameter is configurable only if the IP

Address Assignment Type is set to Static.

• Subnet Mask: The mask of the subnet to which the unit is connected (the default subnet mask is 255.255.255.0).

This parameter is configurable only if the IP Address Assignment Type is set to Static.

• Default Router IP Address: The IP address of the default gateway. This parameter is configurable only if the IP

Address Assignment Type is set to Static.
