Psion Teklogix 7530 Hand-Held Computer User Manual265
Chapter 7: Peripheral Devices & Accessories
Portable Docking Module (PDM)
• Align the pins on the PDM with the connectors on the base of the 7530.
• Gently snap the PDM into place on the base of the unit. Figure 7.1 on
page 266 provides a visual representation of how to secure the PDM.
Note: The latching mechanism on the PDM is designed for quick installation
and release. It is not meant for heavy duty use.
Psion Teklogix recommends using a powered cradle or combo charger in
harsh environments.
BEFORE
DETACHING THE PDM FROM THE 7530, it is critical that you
carry out the following instructions:
• Unplug any external USB devices (mouse, etc.) from the PDM, or
• Turn off the 7535 hand-held before removing the PDM.
Warning: USB devices that are left attached to a PDM at the time that the
PDM is detached from the hand-held can be irreparably damaged
(burned out).
