MP3
Therapy Beam Analyzer
Operating Manual – Installation of the System for Measurement
34 D175.131.00/11 en
• Slide the chamber into the guide tube such that
the chamber protrudes at the front of the tube.
• Lock the chamber with the clamping device.
• Connect extension cable to the chamber and to
the detector input REF on the rear of the
TANDEM.
• Secure the chamber connector with the clamp-
ing screw.
For use of Bragg Peak chambers T34070 or
T34080 as reference detector
• Mount the reference detector holder
T4316/U561 to the upper edge of the Perspex
wall.
• Secure the rod at the holder.
• Insert the chamber into the holder.
• Lock the chamber with the clamping screw.
• Connect extension cable to the chamber and to
the detector input REF on the rear of the
TANDEM.
• Secure the chamber connector with the clamp-
ing screw.
NOTE
This chamber type is only used for Proton beam
or Particle beam.
The chamber has to be positioned in the central
beam.
