MP3
Therapy Beam Analyzer
Technical Manual – Technical Specifications
42 D175.131.00/11 en
6.2 Perspex Tank MP3
Material PMMA
Outside dimensions (LxWxH) 734 mm x 636 mm x 522.5 mm
Inside dimensions (LxWxH) 694 mm x 596 mm x 502.5 mm
Wall thickness 20 mm
Max. water quantity 200 l
Weight 54 kg
6.3 Moving Mechanism
Reproducibility 0.1 mm
Minimum step size 0.1 mm
Maximum speed 50 mm/s
Moving range without detectors 600 mm x 500 mm x 408 mm
6.4 Positioning Device, rotatable, T4316/U182
Adjustments:
Vertical, travel of ± 10 mm
Horizontally in the plane ± 10 mm
Pivoting around vertical
axis
approx. ± 1 °
Rotatable to positions 0°, ± 45° and ± 90°
Outside dimensions (LxW) 769 mm x 671 mm
Overall height in middle position 117.5 mm
Outside dimensions of the sup-
port plate (LxW)
734 mm x 636 mm
Support plate material 5 mm aluminum, anodized
Weight approx. 28 kg
