MP3
Therapy Beam Analyzer
Technical Manual – Technical Specifications
D175.131.00/11 en 43
6.5 MP3 Lifting Carriages T43162
Outside dimensions (LxW) 1120 mm x 780 mm
Outside dimensions of the plat-
form (LxW)
1025 mm x 775 mm
Elevation range, upper platform
edge
454 mm to 869 mm
Elevation range, water surface approx. 1074 mm to 1489 mm (with positioning device)
Time for full lift approx. 45 s
Carrying capacity 300 kg
Weight approx. 150 kg
Power supply (100 … 240) VAC, (50 … 60) Hz, 1A
Fuse 1 piece 3.15 A slow blow (PTW order number L251021)
6.6 MP3 Water Reservoirs T43163-230A and T43163-115A
Outside dimensions (LxWxH) 870 mm x 675 mm x 915 mm
Weight approx. 105 kg
Tank capacity approx. 220 l
Pump type centrifugal pump, self-priming
Pumping capacity approx. 30 l/min
Pump time for entire water quan-
tity
approx. 7 min
Material of the entire water reser-
voir
polypropylene
Power supply
230 V, (50 … 60) Hz, 3.1A
115 V, (50 … 60) Hz, 6.2A
Fuse
T43163-230A
T43163-115A
1 piece 6.3 A slow blow (PTW order number L251010)
1 piece 10 A slow blow (PTW order number L251027)
