ConveyLinx-IO User’s Guide
Publication ERSC-1008 Rev 1.1 – October 2017
INPUT ASSEMBLY (CONVEYLINX-IO PLC)
Register Name /
Module Address
Assembled Address
for PLC
Description
Inputs
4:0035
M: 4:13500
E: I.Data[0]
Bitwise Value - Read only
bit 00 = Left Male Pin 2
bit 01 = Left Female Pin 2
bit 02 = Right Male Pin 2
bit 03 = Right Female Pin 2
bit 04 = Left Male Pin 4
bit 05 = Left Female Pin 4
bit 06 = Right Male Pin 4
bit 07 = Right Female Pin 4
bit 08 = Error Left Male Pin 2
bit 09 = Error Left Female Pin 2
bit 10 = Error Right Male Pin 2
bit 11 = Error Right Female Pin 2
bit 12 = Error Left Male Pin 4
bit 13 = Error Left Female Pin 4
bit 14 = Error Right Male Pin 4
bit 15 = Error Right Female Pin 4
See Note ⑤
NOTE ⑤
Bits 8 through 15 indicate error conditions for each port pin when they are configured as outputs. If any of these
bits are set, it indicates that there is an over-current or short circuit detected on its respective port’s power supply.
OUTPUT ASSEMBLY (PLC CONVEYLINX-IO)
Register Name /
Module Address
Assembled Address
for PLC
Description
Outputs
4:0037
M: 4:13600
E: O.Data[0]
Set bit to energize Output
bit 0 : Left Male Pin2
bit 1 : Left Female Pin2
bit 2 : Right Male Pin2
bit 3 : Right Female Pin2
bit 4 : Left Male Pin4
bit 5 : Left Female Pin4
bit 6 : Right Male Pin4
bit 7 : Right Female Pin4
bit 8 to bit 15 - reserved
These bits are only recognized for a given port pin if it has been configured as an
Output
NOTE ⑥
These bits are only recognized for a given port Pin if it has been configured as an Output
