NODE IDENTIFICATION
EasyRollmain screen has a feature identified as “Blink & Wink” that allows you to visually verify the Node y o u h a v e
selected.
If a valid Node is selected in the first text box in
the “Node No.” area and its information is
displayed on the main screen; clicking the
“Blink&Wink” switch will signal the selected
ConveyLinx module to blink on and off all of its
LED indicators. Click the “Blink&Wink” switch
again to turn this off.
