ConveyLinx-IO User’s Guide
Publication ERSC-1008 Rev 1.1 – October 2017
Register Name /
Module Address
Assembled Address
for PLC
Description
Output Polarity
4:0038
M: 4:13802
E: I.Data[2]
Outputs Polarity Configuration
0 = Output signal and logic states equal
1 = Invert logic from signal state
bit 0 : Left Male Pin2
bit 1 : Left Female Pin2
bit 2 : Right Male Pin2
bit 3 : Right Female Pin2
bit 4 : Left Male Pin4
bit 5 : Left Female Pin4
bit 6 : Right Male Pin4
bit 7 : Right Female Pin4
bit 8 to bit 15 - reserved
See Note ② Error! Reference source not found.
PushPull
4:0496
M: 4:13803
E: I.Data[3]
Push/Pull Inputs Configuration
0 = Input circuit Not Push-Pull type
1 = Input circuit is Push-Pull type
bit 0 : Left Male Pin2
bit 1 : Left Female Pin2
bit 2 : Right Male Pin2
bit 3 : Right Female Pin2
bit 4 : Left Male Pin4
bit 5 : Left Female Pin4
bit 6 : Right Male Pin4
bit 7 : Right Female Pin4
bit 8 to bit 15 - reserved
See Note ③
State On Disconnect
4:0255
M: 4:13804
E: I.Data[4]
Output State on Disconnect Configuration
0 = Output Pin de-energizes upon communication loss with remote controller
1 = Output Pin remains in last state upon communication loss with remote
controller
bit 0 : Left Male Pin2
bit 1 : Left Female Pin2
bit 2 : Right Male Pin2
bit 3 : Right Female Pin2
bit 4 : Left Male Pin4
bit 5 : Left Female Pin4
bit 6 : Right Male Pin4
bit 7 : Right Female Pin4
bit 8 to bit 15 - reserved
See Note ④
NOTE ①
This register is only used for Pins configured as Inputs in the Input/Output register. If a given Pin’s corresponding
bit is 0 in this register, the logical state of the Pin’s data seen in the Inputs register of the Inputs Assembly will
match the logical state of the electrical signal on the Pin. If a given Pin’s corresponding bit is 1 in this register, the
