Pulseroller ConveyLinx-IO User Manual

59
Connecting to a Remote PLC Controller
Publication ERSC-1008 Rev 1.1 – October 2017
CONVEYLINX IO CONFIGURATION DATA
The configuration data is sent from the controller to the module upon initial connection in order to set optional
module operational parameters.
REGISTER CHART LEGEND
M: 4:1502
E: I.Data[2]
CONFIGURATION ASSEMBLY
This chart shows the data sent to the PLC from the module when connected. All registers in the module are 16-bit
integer data type.
Register Name /
Module Address
Assembled Address
for PLC
Description
Input/Output
4:0497
M: 4:13800
E: C.Data[0]
Input/Output Configuration
1 = set Pin as Output
0 = set Pin as Input
bit 0 : Left Male Pin2
bit 1 : Left Female Pin2
bit 2 : Right Male Pin2
bit 3 : Right Female Pin2
bit 4 : Left Male Pin4
bit 5 : Left Female Pin4
bit 6 : Right Male Pin4
bit 7 : Right Female Pin4
bit 8 to bit 15 - reserved
Input Polarity
4:0034
M: 4:13801
E: I.Data[1]
Inputs Polarity Configuration
0 = Input signal and logic states equal
1 = Invert logic from signal state
bit 0 : Left Male Pin2
bit 1 : Left Female Pin2
bit 2 : Right Male Pin2
bit 3 : Right Female Pin2
bit 4 : Left Male Pin4
bit 5 : Left Female Pin4
bit 6 : Right Male Pin4
bit 7 : Right Female Pin4
bit 8 to bit 15 - reserved
See Note ①
Indicates Modbus TCP Addressing Notation
Indicates Ethernet I/P Addressing Notation
