Pulseroller ConveyLinx-IO User Manual

23
Status Indicators
Publication ERSC-1008 Rev 1.1 – October 2017
STATUS INDICATORS
ConveyLinx-IO module status is indicated by several LED’s. All LED’s with the exception of the Ethernet Link and
Activity LEDs are multi-coloured and context sensitive. The following chart indicates the various meanings of all
ConveyLinx-IO LED indicators. Please refer to Figure 2 on page 15 for the item number locations on the module.
By definition Blinking is approximately ½ second on/off cycle and Flashing is approximately ¼ second on/off cycle.
COMMUNICATIONS
Indicator
Item
LED State
Description
Ethernet Left Link &
Ethernet Right Link
On the RJ-45
connectors
(13&14)
OFF
No connection established
Solid Green
Connection is established
Blinking Green
When data transmission activity is occurring
NETWORK & MODULE FUNCTION
Indicator
Item
LED State
Description
Module Status
6
Blinking Red
ConveyLinx-IO is starting task processes
Blinking Green
ConveyLinx-IO is ready
Flashing Green &
Blinking Red
Failsafe Mode
Flashing Red
Auto Configure Mode is active
Blinking Amber
Connection to peer lost or performing firmware
upgrade check
Solid Amber
Firmware upgrade in progress
INPUTS
Indicator
Item
LED State
Description
Left & Right IO LEDs
2, 3, 4 & 5
OFF
Inputs are OFF
Solid Green
Input pin4 is ON
Solid Red
Input pin2 is ON
OUTPUTS
Indicator
Item
LED State
Description
Left & Right IO LEDs
2 & 3 & 4
& 5
OFF
Outputs are OFF
Flash Green
Output pin4 is ON
Flash Red
Output pin2 is ON
