QuadTech 1730T User Manual

Operation 150821/A4 Page 29 of 110
2.3.1 VM/IM Display
The voltage across the DUT and the current through the DUT can be displayed along with the
measured value when VM/IM is set to ON. VM/IM can be selected OFF/ON. The instrument
default setting is OFF. To change the VM/IM Display press [SYSTEM SETUP], [SYSTEM
CONFIG] and the down arrow [⇓] until the box next to VM/IM DISPLAY is highlighted, then
press [F1] = ON to display the current and voltage across the DUT, or [F2] = OFF.
VM / IM DISPLAY:
CONST Rsource:
<SYSTEM CONFIG>
OFF
F1
ON
non-operational
Go to CONST Rsource
Select VM & IM ON
AVERAGE TIME:
CABLE LENGTH:
BEEPER:
OFF
LOW
0M
001
100/25 OHM
F2
F3
Select VM & IM OFF
Default: OFF
KEY LOCK: OFF
2.3.2 CONST Rsource
The constant source impedance of the 1730T instrument can be set to 100/25Ω, 100Ω, 25Ω, or
10ΩCC (constant current). The instrument default setting is 100/25Ω.
The 100/25Ω setting allows the instrument to automatically select its impedance based on the
impedance of the DUT (Z
DUT
). If Z
DUT
is <10Ω, then the 1730T CONST Rsource = 25Ω. If Z
DUT
is ≥10Ω, then the 1730T CONST Rsource = 100Ω.
The 10ΩCC setting puts a constant current equal to 100mA across the DUT when the test
voltage is set to 1V. If Z
DUT
is ≥10Ω, then the 1730T instrument CONST Rsource = 10Ω.
To change the source resistance press [SYSTEM SETUP], [SYSTEM CONFIG] and the down
arrow [⇓] until the box next to CONST Rsource is highlighted, then press [F1] =100/25Ω, [F2]
=100Ω, [F3] = 10Ωc.c. or [F4] = Next Page. On next page [F1] = 25Ω.
F2
100 OHM
10 OHM/C.C. (constant current)
100/25 OHM
<SYSTEM CONFIG>
100/25 OHM
100 OHM
LOW
0M
001
100/25 OHM
OFFVM / IM DISPLAY:
BEEPER:
CABLE LENGTH:
AVERAGE TIME:
CONST Rsource:
F1
Go to AVERAGE Time
Go to VM / IM Display
KEY LOCK: OFF
NEXT P. 1/2
10 OHM/C.C.
F3
F4 F1
= 25 OHM
Default: OFF
