QuadTech 1730T User Manual

Page 54 of 110 150821/A4 Operation
2.5.3 RECALL
The 1730T instrument’s STORE and RECALL functions are within the MAIN INDEX menu.
Press [MAIN INDEX], press [F1] = BINNING (or [F2] = COMPARE) then press [F3] =
RECALL to access the recall function.
When performing the STORE and RECALL functions, the 1730T instrument stores the
following information:
• Frequency
• Speed
• Level
• Parameter
• Range
• All Bin setting values (excluding the Bin Counter)
• All Compare setting values (excluding the Compare Counter)
There are 50 storage locations (00 – 49) in the 1730T instrument memory.
CORRECTION
< MAIN INDEX >
COMPARE
BINNING
Enter Compare function
Enter Binning function
Enter Correction function
F2
F3
F1
BIN COUNT
< MAIN INDEX BINNING >
BIN SET
STORE
RECALL
Set Bin Nominal, High & Low Values
Recall Results from Memory Location 00 -49
Store Results to Memory Location 00-49
PARAMETER:
AUX_HI:
NOMINAL:
AUX_LO:
+99999.9999 -
00000.0000 pF
Cs - D
+00000.0000 -
F3
F1
F2
F4
View Results by Bin # and Count
(Left & Right arrows also move cursor to next digit)
Go UP in
memory location
Go DOWN in
memory location
TRIGGER
Press TRIGGER to recall setup
If there is no data stored in the location chosen, this message will be displayed:
< MAIN INDEX BINNING >
DIGIT UP
DIGIT DOWN
DIGIT
Increase value of underscored digit
Move underscore cursor to next digit
Decrease value of underscored digit
PARAMETER:
AUX_HI:
NOMINAL:
AUX_LO:
+99999.9999 -
00000.0000 pF
Cs - D
+00000.0000 -
F3
F1
F2
F4
ENTER RECALL NUMBER: 00
PRESS TRIG TO RECALL
< MAIN INDEX BINNING >
DIGIT UP
DIGIT DOWN
DIGIT
Increase value of underscored digit
Move underscore cursor to next digit
Decrease value of underscored digit
PARAMETER:
AUX_HI:
NOMINAL:
AUX_LO:
+99999.9999 -
00000.0000 pF
Cs - D
+00000.0000 -
F3
F1
F2
F4
ENTER RECALL NUMBER: 07
ERROR... NO DATA
