QuadTech 1730T User Manual

Operation 150821/A4 Page 41 of 110
2.4.5 SPEED/Accuracy
Trading accuracy for speed, program the measurement speed of the 1730T instrument to Slow
(3measurements/second), Medium (22 measurements/second) or Fast (66 measurements/second).
The basic LCR accuracy (0.1%) and D accuracy (0.001) are specified for the slow measurement
speed. In MEAS DISPLAY (Pg 2/3) press [F2] so that the MEDIUM box is highlighted. Use
the up arrow [⇑] key to increase the speed or use the down arrow [⇓] key to decrease the speed.
The instrument default setting is MEDIUM (22 meas/second).
NEXT PAGE 2/3
Cs : 1.2345 pF
D : 1.2345
MEAS DISPLAY
RANGE: A 100
Ω
SPEED:
TRIG.: INT
SLOW
F2
Select measurement speed
Decrease speed: Fast/Medium/Slow
Increase speed: Slow/Medium/Fast
3 meas/sec, 22 meas/sec, 66 meas/sec
66 meas/sec, 22 meas/sec, 3 meas/sec
The accuracy of the 1730T instrument depends on the speed of the measurement. Basic
Accuracy for LCR is ±0.1% and basic accuracy for DQ is ±0.001. Basic accuracy is specified for
the speed equal to 3 measurements/second, temperature = 23°C ±5°C, relative humidity (RH)
≤90%.
Table 2-4 lists the basic accuracy for ⏐Z⏐ - θ. For measurements made in fast mode double the
accuracy listed in Table 2-4.
Table 2-4: ⏐Z⏐ - θ Accuracy
Impedance Frequency (Hz)
⏐Z⏐ (Ω)
50 60 100 120 1k 10k 20k 40k 50k 100k
10M
1M
0.6%
0.8°
0.6%
0.8°
0.48%
0.5°
0.4%
0.45°
0.35%
0.4°
1M
100k
0.4%
0.6°
0.4%
0.6°
0.24%
0.33°
0.20%
0.3°
0.16%
0.08°
0.5%
0.12°
1.5%
0.12°
2%
0.24°
2%
0.24°
2%
0.4°
100k
10k
0.3%
0.4°
0.3%
0.4°
0.2%
0.24°
0.2%
0.24°
0.12%
0.06°
0.5%
0.08°
1.5%
0.09°
1.8%
0.24°
1.8%
0.24°
2%
0.3°
10k
1k
0.3%
0.2°
0.3%
0.2°
0.2%
0.2°
0.2%
0.2°
0.1%
0.05°
0.45%
0.07°
0.5%
0.08°
0.6%
0.08°
0.6%
0.08°
0.7%
0.2°
1k
100
0.3%
0.2°
0.3%
0.2°
0.2%
0.2°
0.2%
0.2°
0.1%
0.05°
0.2%
0.07°
0.36%
0.08°
0.4%
0.08°
0.4%
0.08°
0.45%
0.2°
100
10
0.4%
0.2°
0.4%
0.2°
0.25%
0.2°
0.25%
0.2°
0.24%
0.09°
0.26%
0.09°
0.36%
0.15°
0.4%
0.17°
0.4%
0.17°
0.5%
0.2°
10
1
0.5%
0.3°
0.5%
0.3°
0.45%
0.22°
0.4%
0.22°
0.32%
0.09°
0.35%
0.15°
0.4%
0.15°
0.5%
0.17°
0.5%
0.17°
0.6%
0.2°
1
0.1
0.8%
0.4°
0.8%
0.4°
0.7%
0.24°
0.5%
0.24°
0.35%
0.15°
0.35%
0.15°
0.4%
0.2°
0.7%
0.26°
0.7%
0.26°
0.9%
0.6°
