QuadTech 1730T User Manual

Operation 150821/A4 Page 47 of 110
2.4.8 BINNING
The 1730T instrument has 8 pass/fail bins for sorting components by test result. To
enable/disable the binning function, in MEAS DISPLAY (Pg 3/3) press [F2] so that the OFF box
is highlighted. Use the up arrow [⇑] key or down arrow [⇓] key to switch the binning function
ON/OFF. The instrument default setting is OFF. Setting the bin values is done within the
MAIN INDEX menu. Refer to paragraph 2.5.1 for instructions on setup of Binning.
NEXT PAGE 3/3
Cs : 1.2345 pF
D : 1.2345
MEAS DISPLAY
BIAS V: OFF
BINNING:
COMPARE: OFF
OFF
F2
Enable/Disable binning function
Enable/Disable binning function
Enable/Disable binning function
NEXT PAGE 3/3
Cs : 1.2345 pF
D : 1.2345
MEAS DISPLAY
BIAS V: OFF
BINNING:
COMPARE: OFF
ON
F2
Enable/Disable binning function
Enable/Disable binning function
Enable/Disable binning function
BIN: 0
2.4.9 COMPARE
The 1730T instrument has 8 pass/fail bins for sorting components by test result. To
enable/disable the compare function, in MEAS DISPLAY (Pg 3/3) press [F3] so that the OFF
box is highlighted. Use the up arrow [⇑] key or down arrow [⇓] key to switch the compare
function ON/OFF*. The instrument default setting is OFF. Setting the comparison values is
done within the MAIN INDEX menu. Refer to paragraph 2.5.4 for instructions on setup of
Compare.
NEXT PAGE 3/3
Cs : 1.2345 pF
D : 1.2345
MEAS DISPLAY
BIAS V: OFF
BINNING: OFF
OFFCOMPARE:
Enable/Disable compare function
F3
Enable/Disable compare function
Enable/Disable compare function
NEXT PAGE 3/3
Cs : 0.0000 pF
D : 0.5002
MEAS DISPLAY
BIAS V: OFF
BINNING: OFF
ON-VAL
COMPARE:
Enable/Disable compare function
F3
Enable/Disable compare function
Enable/Disable compare function
Cs: GO GOD:
ON-VAL
ON- Δ %
ON- Δ
OFF
Absolute Value
Delta Absolute Value
Delta Percent Absolute Value
Compare Function: OFF
* Refer to “Notes on Compare Settings” on next page.
