QuadTech 1730T User Manual

Page 36 of 110 150821/A4 Operation
2.4 MEAS DISPLAY
The 1730T instrument’s stand-by display is the MEAS DISPLAY. After power has been applied
to the instrument and it cycles quickly through the information screen, the instrument reverts to
the MEAS DISPLAY. To view the instrument information screen as illustrated in Figure 2.1,
press [SYSTEM SETUP] then [⇐].
QuadTech Inc.
1730T LCR Meter
COPYRIGHT (c) JAN 2002
VER: 1.20 DATE: 04/12/2005
Instrument Information
Figure 2.1: Instrument Information Screen
NEXT PAGE 1/4
PARA.: Cs - D
Cs : 1.2345 pF
D : 1.2345
MEAS DISPLAY
NEXT PAGE 2/4
TRIG.: EXT
Cs : 1.2345 pF
D : 1.2345
MEAS DISPLAY
FREQ.: 1.0 kHz
LEVEL: 1.00 V
RANGE: A
SPEED: MEDIUM
MEAS DISPLAY: 4 Pages
Test Frequency
Go to Page 2
Test Parameter
Test Voltage
Measurement Range
Measurement Speed
Instrument Trigger
Go to Page 3
F1
F2
F3
F4
F1
F2
F3
F4
NEXT PAGE 3/4
COMPARE: OFF
Cs : 1.2345 pF
D : 1.2345
MEAS DISPLAY
BIAS V: OFF
BINNING: OFF
Go to Page 4
Compare On/Off
Binning On/Off
Bias On/Off
F1
F2
F3
F4
NEXT PAGE 4/4
Cs : 1.2345 pF
D : 1.2345
MEAS DISPLAY
BIAS I: OFF
BIAS I: 0 A
Go to Page 1
Bias I: 0 (No 1320)
Bias I On/Off
(1320 attached)
F1
F2
F3
F4
Figure 2.2: MEAS DISPLAY
Figure 2.2 illustrates the three pages of parameters that can be programmed within the MEAS
DISPLAY. The binning and comparison functions are enabled/disabled in MEAS DISPLAY
and programmed in MAIN INDEX. The bias voltage function is enabled/disabled in MEAS
DISPLAY and programmed in SYSTEM SETUP. Paragraphs 2.4.1 through 2.4.10 explain each
parameter in detail.
