Accessories
Accessories Included
Item Quantity QuadTech P/N
AC Power Cord 1 4200-0300
Power Line Fuse 1A 250V SB 1 520026
Power Line Fuse 0.5A 250V SB 1 520138
Transformer Test Fixture 1 630166
Lead Set: 4 BNC Connectors to 2 Kelvin Clips 1 1700-03
Instruction Manual 1 150821
Calibration Certificate 1 N/A
Accessories/Options Available
Item Quantity QuadTech P/N
Axial/Radial Component Test Fixture 1 1700-01
Axial/Radial Remote Test Fixture 1 1700-02
Lead Set: 4 BNC Connectors to 2 Kelvin Clips 1 1700-03
BNC to BNC Cable Lead Set (1m) 1 7000-01
BNC to BNC Cable Lead Set (2m) 1 7000-02
Lead Set: 4 BNC Connectors to Chip Component Tweezers 1 7000-05
Low Voltage Chip Component Test Fixture 1 7000-07
50-pin micro-ribbon plug (for Handler) 1 329210
Transformer Test Fixture (standard with unit) 1 630166
NOTE:
For proper operation, the H
CUR
/H
POT
/I
CUR
/I
POT
cable shields must be connected together at the
DUT. This connection is already made using the 1730T recommended accessory leads.
If the shields are not tied together, then at higher frequencies a resonance may occur which could
cause erroneous capacitance readings.
