Specifications (Continued)
Bias Voltage: Internal: (R
BIAS
) 0-5V DC, External: Programmable 0-5V DC
Bias Current: Internal: (R
BIAS
) 0-200mA
Display: 240 x 64 LCD Graphic display
Results Format:
• Value • Deviation • %Deviation • Bin Number
Indication: Audible alarm programmable HI, LOW or OFF for Pass or Fail
Setup Storage: 50 Memory Locations
Standard
Interfaces:
• IEEE-488 • Handler
Connectors: Front Connection: 4 BNC Sockets (L
CUR
, L
POT
, H
POT
, H
CUR
)
Rear Connection: EXT Bias Terminal Strip, 1 BNC Connector
GUARD: Banana Socket (Front & Rear connection)
Front Panel Lockout: Key Lock with or without setup recall, Back Lit Display: LOCK
Mechanical: Bench Mount; Dimensions: (w x h x d): 12.50 x 4.00 x 13.50”)
(312.5 x 100.0 x 337.5 mm)
Weight: 12.4 lbs (5.7 kg) net, 17 lbs (7.8 kg) shipping
Environmental: Operating: 10°C to + 40
o
C, 10-90% RH
Storage: 0°C to + 50
o
C, 10-90% RH
Pollution Degree 2
Installation Category II
Power: • 90-125VAC • 190-250VAC • 50 or 60Hz • 65W max
Supplied: • Instruction Manual • Power Cable
• Calibration Certificate • Kelvin Clip Lead Set
Ordering Information: Description Catalog No.
LCR Meter 1730T
