Specifications
Primary Parameters: Ls, Lp, Cs, Cp, Rs, Rp and ⏐Z⏐, L2A and L2B
Ls, Lp: 0.001μH – 99.999kH
L2A, L2B: 0.001μH – 99.999kH
Cs, Cp: 0.001pF – 9.9999F
Rs, Rp: 0.01mΩ – 99.99MΩ
⏐Z⏐: 0.01mΩ – 99.99MΩ
Secondary Parameters: D, Q, ESR, Xs, θ, N, 1/N, M, R2, and DCR
D: 0.0001 – 9999
Q: 0.0001 – 9999
ESR: 0.01mΩ – 99.99MΩ
Xs: 0.01mΩ – 99.99MΩ
θ: -180.00° – 180.00°
N: 0.001 – 9999.9
1/N: 0.001 – 9999.9
M: 0.001μH – 99.999kH
R2: 0.01mΩ – 99.99MΩ
DCR 0.01mΩ – 99.99MΩ
Measurement Accuracy: Basic LCR: 0.1% Basic DQ: ±0.001
Measurement Rate: Fast: 62 measurements/second
Medium: 19 measurements/second
Slow: 3 measurements/second
Measurement Mode: Continuous or Trigger (INT, EXT or Manual)
Measurement Delay: 0 – 10 seconds in 1ms increments
Averaging: 1-256 measurements
Ranging: Automatic or User Selectable
Equivalent Circuit: Series or Parallel
Test Voltage: 10mV to 1.0V programmable in 10mV steps
Test Frequency: 10 User Selectable Test Frequencies: 50Hz, 60Hz, 100Hz, 120Hz,
1kHz, 10kHz, 20kHz, 40kHz, 50kHz and 100kHz
Accuracy: ± (0.01% ±0.01Hz)
Source Impedance: 100/25Ω: 100Ω±5% if DUT
IMPEDANCE
> 1Ω; 25 Ω±5% if DUT
IMPEDANCE
< 1Ω;
10Ω/CC: 10Ω±10% if DUT
IMPEDANCE
> 10Ω; CC: 100mA±5% if DUT
IMPED
< 10Ω
100Ω: 100Ω±5%; 25Ω±5%;
25Ω: 25Ω±5%;
