Interface 150821/A4 Page 97 of 110
Figure 3-7 illustrates the connection of the handler interface to the main board on the 1730T.
Figure 3-7: Connection of 1730T Handler Interface to Main Board
1
12
2
24
23
22
21
20
19
17
16
15
14
/BIN9
/EOT
/BIN7
/BIN2
/BIN1
/BIN6
/BIN0
/BIN5
/BIN3
/BIN8
/BIN4
/ACQ
VEXT
25 50
49
48
47
41
42
43
44
45
46
35
36
37
38
39
40
29
30
31
32
33
34
26
27
28
VEXT
/EXT
COM
COM
NC
COM
COM
NC
NC
NC
NC
NC
NC
GND
GND
VEXT
VEXT
+5
/BIN0
/BIN1
/BIN2
/BIN4
/BIN3
/BIN5
/BIN8
/BIN6
/BIN7
/BIN9
/ACQ
/EOT
Pull-Up
Resistors
Handler
Interface
MAIN
BOARD
(1730)
