Q24/Q48 Tape Library Installation and Operations Manual
2.7 Removing the shipping lock
The shipping lock, which prevents the media changer transport
mechanism from moving during shipment, must be removed
before the library is powered on.
To remove and store the shipping lock:
1. Remove the yellow label that is securing the shipping lock on the top of the library.
2. Remove the shipping lock.
3. Store the shipping lock in the slot provided on the rear panel (Important: The lock is required
if the library is to be returned or transported to a new location at some future time).
4. Replace the yellow label on the top of the library.
Figure 11 Removing and Storing the Shipping Lock on a Q24
Figure 12 Removing and Storing the Shipping Lock on a Q48
© Copyright QUALSTAR 2015 13
