MITX-DNV0 Series - User Guide, Rev. 1.2
www.quanmax.com
// 19
Software
OS Support Windows Server, Linux
Mechanical
Dimension (L x W) Mini-ITX (170 mm x 170 mm / 6.70" x 6.70")
3.3. Environmental Conditions
The MITX-DNV0 Series is compliant with the following environmental conditions. It is the customer's responsibility to
provide sufficient airflow around each of the components to keep them within the allowed temperature range.
Table 2: Environmental Conditions
Operating Temperature 0 °C ~ 60 °C / 32 °F ~ 140 °F (Standard)
-20 °C ~ 70 °C / -4 °F ~ 158 °F (Extended)
Storage Temperature -20 °C ~ 80 °C / -4 °F ~ 176 °F (Standard)
-40 °C ~ 85 °C / -40 °F ~ 185 °F (Extended)
Humidity 0 % ~ 95 %
3.4. Standards and Certifications
The MITX-DNV0 Series meets the following standards and certification tests.
Table 3: Standards and Certifications
CE
EN 55022: 2010 + AC: 2011 Class A
EN 55024: 2010
EN 61000-3-2: 2006 + A1: 2009 + A2: 2009 Class D
EN 61000-3-3: 2013
EN 60950-1: 2006 + A11: 2009 + A1: 2010 + A12: 2011 + A2: 2013
IEC 60950-1: 2005 (Second Edition) + Am 1: 2009 + Am 2: 2013
FCC
FCC CFR Title 47 Part 15 Subpart B: 2014
ANSI C63.4-2009
ICES-003 Issue 5: 2012
CISPR 22: 2008
CAN/CSA-CISPR 22-10
3.5. Processor Support
The MITX-DNV0 Series is designed to support Intel® Denverton Processors, Atom™ C3000 Series. The BGA CPU is
remounted from factory. Quanmax has defined the board versions as listed in the following table, so far all based on
Embedded CPUs. Other versions are expected at a later date.
Table 4: Processor Support
Name Core # Speed Turbo Embedded Cache Socket TDP Tj
Atom™ C3338 2 1.50 GHz 2.20 GHz Yes 4M FCBGA1310 9 W 100 °C
Atom™ C3538 4 2.10 GHz 2.10 GHz Yes 8M FCBGA1310 15 W 100 °C
