Quanmax MITX-DNV0 Series User Manual

MITX-DNV0 Series - User Guide, Rev. 1.2
www.quanmax.com
// 73
Figure 49: BIOS Advanced Menu - Serial Port Console Redirection - COM1 / COM2 Console Redirection Settings
BIOS SETUP UTILITY
Main Advanced Power Boot Security Save & Exit
COM1
Console Redirection Settings
Terminal Type [ANSI]
Bits per second [115200]
→ ←: Select Screen
Data Bits [8]
↑ ↓: Select Item
Parity [None] Enter: Select
Stop Bits [1] +/-: Change Opt.
Flow Control [None] F1: General Help
VT-UTF8 Combo Key Support [Enabled] F2: Previous Values
Recorder Mode [Disabled] F3: Optimized Defaults
Resolution 100x31 [Disabled] F4: Save & Exit
Putty KeyPad [VT100] ESC: Exit
Version 2.19.1266. Copyright (C) 2018, American Megatrends, Inc.
Feature Option Description
Terminal Type [VT100], [VT100+],
[VT-UTF8], [ANSI]
Determine the terminal type.
Bits per second [9600], [19200],
[38400], [57600],
[115200]
Select serial port transmission speed. The speed must be
matched on the other side. Long or noisy lines may require
lower speeds.
Data Bits [7], [8] Determine the data bits.
Parity [None], [Even], [Odd],
[Mark], [Space]
A parity bit can be sent with the data bits to detect some
transmission errors.
Stop Bits [1], [2] Stop bits indicate the end of a serial data packet (A start bit
indicates the beginning.). The standard setting is 1 stop bit.
Communication with slow devices may require more than 1 stop
bit.
Flow Control [None], [Hardware
RTS/CTS]
Flow control can prevent data loss from buffer overflow. When
sending data, if the receiving buffers are full, a 'stop' signal can
be sent to stop the data flow. You may select “None” or
“Hardware RTS/CTS” depending on the circumstances.
VT-UTF8 Combo Key
Support
[Disabled], [Enabled] Select whether to enable or disable VT-UTF8 Combination Key
Support for ANSI/VT100 terminals.
Recorder Mode [Disabled], [Enabled] Select whether to enable or disable recorder mode. With this
mode enabled, only text will be sent. This is to capture terminal
data.
Resolution 100x31 [Disabled], [Enabled] Select whether to enable or disable extended terminal
resolution.
Putty KeyPad [VT100], [LINUX],
[XTERMR6], [SCO],
[ESCN], [VT400]
Select FunctionKey and KeyPad on Putty.
