Feature Option Description
Serial Port 1 Type [RS232], [RS422],
[RS485]
Select an appropriate type for Serial Port 1.
RS485 Duplex Mode [Half Duplex], [Full
Duplex]
Select an appropriate RS485 Duplex Mode.
RS485 Auto Flow
Control
[Disabled], [Enabled] Select whether to enable or disable RS485 Auto Flow Control.
Figure 47: BIOS Advanced Menu - Super IO Configuration - Serial Port 2 Configuration
BIOS SETUP UTILITY
Main Advanced Power Boot Security Save & Exit
Serial Port 2 Configuration
Serial Port [Enabled]
→ ←: Select Screen
Device Settings IO=2F8h; IRQ=3;
↑ ↓: Select Item
Enter: Select
Change Setting [Auto] +/-: Change Opt.
Serial Port 2 Type [RS232] F1: General Help
RS485 Deplux Mode* [Half Duplex] F2: Previous Values
RS485 Auto Flow Control [Disabled] F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.19.1266. Copyright (C) 2018, American Megatrends, Inc.
* These items appear only when selecting RS485 for the Serial Port 2 Type.
Feature Option Description
Serial Port [Disabled], [Enabled] Select whether to enable or disable Serial Port (COM).
Change Settings [Auto], [IO=2F8h;
IRQ=3;], [IO=3F8h;
IRQ=3, 4, 5, 6, 7, 9, 10,
11, 12;], [IO=2F8h;
IRQ=3, 4, 5, 6, 7, 9, 10,
11, 12;], [IO=3E8h;
IRQ=3, 4, 5, 6, 7, 9, 10,
11, 12;], [IO=2E8h;
IRQ=3, 4, 5, 6, 7, 9, 10,
11, 12;]
Select an optional setting for Super IO device.
Serial Port 2 Type [RS232], [RS422],
[RS485]
Select an appropriate type for Serial Port 2.
RS485 Duplex Mode [Half Duplex], [Full
Duplex]
Select an appropriate RS485 Duplex Mode.
RS485 Auto Flow
Control
[Disabled], [Enabled] Select whether to enable or disable RS485 Auto Flow Control.
