Quanmax MITX-DNV0 Series User Manual

MITX-DNV0 Series - User Guide, Rev. 1.2
www.quanmax.com
// 69
Figure 44: BIOS Advanced Menu - DIO Configuration
BIOS SETUP UTILITY
Main Advanced Power Boot Security Save & Exit
DIO Configuration
User Configuration [Disabled]
DIO_0* [Output High]
DIO_1* [Output High]
DIO_2* [Output High]
DIO_3* [Output High]
DIO_4* [Output High]
DIO_5* [Output High]
DIO_6* [Output High]
DIO_7* [Output High]
→ ←: Select Screen
DIO_0 Value 1
↑ ↓: Select Item
DIO_1 Value 1 Enter: Select
DIO_2 Value 1 +/-: Change Opt.
DIO_3 Value 1 F1: General Help
DIO_4 Value 1 F2: Previous Values
DIO_5 Value 1 F3: Optimized Defaults
DIO_6 Value 1 F4: Save & Exit
DIO_7 Value 1 ESC: Exit
Version 2.19.1266. Copyright (C) 2018, American Megatrends, Inc.
* These items appear only when enbling User Configuration.
Feature Option Description
User Configuration [Enabled], [Disabled] Select whether or not to allow user to set the DIO pin value.
DIO_0..7 [Output Low], [Output
High], [Input]
Set up the DIO pin value.
